Shop 55BDL3005X 55" FHD Video Wall Display

End of Life

SKU: 55BDL3005X

Signage Size: 55"

Video Wall Display 55" Direct LED Backlight, Full HD, 500cd/m2

Datasheet

Description

55" Direct LED Backlight, Full HD, 500cd/m2

55"
Direcrt LED Backlight
Full HD
500cd/m2

Download

Datasheet

More Information

Brand	Philips
Specifications	Diagonal screen size (metric) 138.7 cm Diagonal screen size (inch) 54.6 inch Panel resolution 1920x1080p Optimum resolution 1920 x 1080 @ 60 Hz Brightness 500 cd/m² Contrast ratio (typical) 1400:1 Dynamic contrast ratio 500,000:1 Response time (typical) 8 ms Aspect ratio 16:9 Viewing angle (horizontal) 178 degree Viewing angle (vertical) 178 degree Pixel pitch 0.63 x 0.63 mm Display colors 1073 M Picture enhancement 3/2 - 2/2 motion pull down 3D Combfilter Motion compens. deinterlacing Progressive scan 3D MA deinterlacing Dynamic contrast enhancement Supported Display Resolution Computer formats 3840 x 2160, 30Hz 1920 x 1200, 60Hz 1920 x 1080, 60Hz 1600 x 1200, 60Hz 1440 x 900, 60Hz 1366 x 768, 60Hz 1360 x 768, 60Hz 1280 x 1024, 60Hz 1280 x 800, 60Hz 1280 x 768, 60Hz 1024 x 768, 60Hz 800 x 600, 56, 60, 72, 75Hz 640 x 480, 60, 67, 72, 75Hz Video formats 2160p, 30Hz 1080p, 50, 60Hz 1080i, 50, 60Hz 720p, 50, 60Hz 576p, 50Hz 576i, 50Hz 480p, 60Hz 480i, 60Hz Connectivity Video input Component (RCA) Composite (RCA) DVI-D HDMI (x2) VGA (Analog D-Sub) DisplayPort (1.2) Video output DisplayPort DVI-I VGA (via DVI-I) Audio input 3.5 mm jack Audio Left/Right (RCA) Audio output Audio Left/Right (RCA) External speaker connector External control IR (in/out) 3.5 mm jack RJ45 RS232C (in/out) 2.5 mm jack Other connections OPS Convenience Signal Loop Through RS232 VGA DisplayPort DVI IR Loopthrough Ease of installation Carrying Handles Energy saving functions Ambient light sensor Smart Power Network controllable RS232 Card OPS RS232 RJ45 One Wire (HDMI-CEC) Placement Portrait Landscape Screen saving functions Pixel Shift, Low Bright Tiled Matrix Up to 10 x 10 Dimensions Bezel thickness 3.5 mm Bezel width Top/Left: 2.3mm, Bottom/Right: 1.2mm Set Width 1213.4 mm Set Height 684.2 mm Set Depth 107.65 mm Product weight 26.5 kg VESA Mount 400 x 400 mm Product weight (lb) 58.42 lb Set Depth (inch) 4.23 inch Set Height (inch) 26.93 inch Set Width (inch) 47.77 inch Operating conditions Temperature range (operation) 0 ~ 40 °C Temperature range (storage) -20 ~ 60 °C Altitude 0 ~ 3000 m Relative humidity 20 ~ 80 % MTBF 60,000 hour(s) Power Mains power 110-240V Consumption (On mode) 110 W (EnergyStar 6.0 test method) Standby power consumption <0.5W Sound Built-in speakers 2 x 10W (RMS) Accessories Included Accessories IR cable IR sensor cable (1.8 m) RS232 daisy-chain cable RS232 DB9 adapter cable Thumb Screw Included accessories Remote Control Batteries for remote control AC Power Cord Quick start guide Edge alignment pins Edge alignment plates DVI-D cable Optional accessories Edge finishing kit ColourCalibrationKit (CCK4602) IR Light Motion Sensor (CRD41) Miscellaneous On-Screen Display Languages Arabic Simplified Chinese Traditional Chinese English French German Italian Japanese Polish Russian Spanish Turkish Regulatory approvals CE FCC, Class B UL/cUL CB GOST EPEAT Warranty 3 year warranty

Brand

Philips

Specifications

Diagonal screen size (metric)

138.7 cm

Diagonal screen size (inch)

54.6 inch

Panel resolution

1920x1080p

Optimum resolution

1920 x 1080 @ 60 Hz

Brightness

500 cd/m²

Contrast ratio (typical)

1400:1

Dynamic contrast ratio

500,000:1

Response time (typical)

8 ms

Aspect ratio

16:9

Viewing angle (horizontal)

178 degree

Viewing angle (vertical)

178 degree

Pixel pitch

0.63 x 0.63 mm

Display colors

1073 M

Picture enhancement
- 3/2 - 2/2 motion pull down
- 3D Combfilter
- Motion compens. deinterlacing
- Progressive scan
- 3D MA deinterlacing
- Dynamic contrast enhancement
Supported Display Resolution
Computer formats
- 3840 x 2160, 30Hz
- 1920 x 1200, 60Hz
- 1920 x 1080, 60Hz
- 1600 x 1200, 60Hz
- 1440 x 900, 60Hz
- 1366 x 768, 60Hz
- 1360 x 768, 60Hz
- 1280 x 1024, 60Hz
- 1280 x 800, 60Hz
- 1280 x 768, 60Hz
- 1024 x 768, 60Hz
- 800 x 600, 56, 60, 72, 75Hz
- 640 x 480, 60, 67, 72, 75Hz
Video formats
- 2160p, 30Hz
- 1080p, 50, 60Hz
- 1080i, 50, 60Hz
- 720p, 50, 60Hz
- 576p, 50Hz
- 576i, 50Hz
- 480p, 60Hz
- 480i, 60Hz
Connectivity
Video input
- Component (RCA)
- Composite (RCA)
- DVI-D
- HDMI (x2)
- VGA (Analog D-Sub)
- DisplayPort (1.2)
Video output
- DisplayPort
- DVI-I
- VGA (via DVI-I)
Audio input
- 3.5 mm jack
- Audio Left/Right (RCA)
Audio output
- Audio Left/Right (RCA)
- External speaker connector
External control
- IR (in/out) 3.5 mm jack
- RJ45
- RS232C (in/out) 2.5 mm jack
Other connections

OPS
Convenience
Signal Loop Through
- RS232
- VGA
- DisplayPort
- DVI
- IR Loopthrough
Ease of installation

Carrying Handles

Energy saving functions
- Ambient light sensor
- Smart Power
Network controllable
- RS232
- Card OPS RS232
- RJ45
- One Wire (HDMI-CEC)
Placement
- Portrait
- Landscape
Screen saving functions

Pixel Shift, Low Bright

Tiled Matrix

Up to 10 x 10
Dimensions

Bezel thickness

3.5 mm

Bezel width

Top/Left: 2.3mm, Bottom/Right: 1.2mm

Set Width

1213.4 mm

Set Height

684.2 mm

Set Depth

107.65 mm

Product weight

26.5 kg

VESA Mount

400 x 400 mm

Product weight (lb)

58.42 lb

Set Depth (inch)

4.23 inch

Set Height (inch)

26.93 inch

Set Width (inch)

47.77 inch
Operating conditions

Temperature range (operation)

0 ~ 40 °C

Temperature range (storage)

-20 ~ 60 °C

Altitude

0 ~ 3000 m

Relative humidity

20 ~ 80 %

MTBF

60,000 hour(s)
Power

Mains power

110-240V

Consumption (On mode)

110 W (EnergyStar 6.0 test method)

Standby power consumption

<0.5W
Sound

Built-in speakers

2 x 10W (RMS)
Accessories
Included Accessories
- IR cable
- IR sensor cable (1.8 m)
- RS232 daisy-chain cable
- RS232 DB9 adapter cable
- Thumb Screw
Included accessories
- Remote Control
- Batteries for remote control
- AC Power Cord
- Quick start guide
- Edge alignment pins
- Edge alignment plates
- DVI-D cable
Optional accessories
- Edge finishing kit
- ColourCalibrationKit (CCK4602)
- IR Light Motion Sensor (CRD41)
Miscellaneous
On-Screen Display Languages
- Arabic
- Simplified Chinese
- Traditional Chinese
- English
- French
- German
- Italian
- Japanese
- Polish
- Russian
- Spanish
- Turkish
Regulatory approvals
- CE
- FCC, Class B
- UL/cUL
- CB
- GOST
- EPEAT
Warranty

3 year warranty
