Specifications |
Picture/Display
- Diagonal screen size: 74.5 inch / 189.3 cm
- Panel resolution: 3840 x 2160
- Optimum resolution: 3840 x 2160 @60Hz
- Brightness: 400 cd/m²
- Contrast ratio (typical): 1200:1
- Dynamic contrast ratio: 500,000:1
- Aspect ratio: 16:9
- Response time (typical): 8 ms
- Pixel pitch: 0.4296 x 0.4296 mm
- Display colors: 1.07 Billion
- Viewing angle (H / V): 178 / 178 degree
- Picture enhancement: 3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. deinterlacing, progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement
- Clinical image: D-Image preset (Dicom part 14 compatible)
- Operating system: Android 8.0
- Panel technology: ADS
Connectivity
- Video input: DVI-D (x1), HDMI 2.0 (x3), USB 2.0 (x2), VGA (Analog D-Sub) (x1)
- Audio input: 3.5 mm jack
- Audio output: 3.5mm jack
- External control: RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack, RJ45
- Other connections: OPS
Supported Display Resolution
• Computer formats (Resolution & Refresh rate)
- 1920 x 1080 60Hz
- 1680 x 1050 60Hz
- 1600 x 1200 60Hz
- 1440 x 900 60Hz
- 1280 x 1024 60Hz
- 1280 x 800 60Hz
- 1280 x 720 60Hz
- 1152 x 870 75Hz
- 1024 x 768 60, 70, 75Hz
- 800 x 600 56, 60, 72, 75Hz
- 720 x 400 70Hz
- 640 x 480 60, 67, 72, 75Hz
- 1152 x 864 75Hz
- 832 x 624 75Hz
• Video formats (Resolution & Refresh rate)
- 3840 x 2160 60Hz
- 3840 x 2160 30Hz
- 576p 50Hz
- 576i 50Hz
- 480p 60Hz
- 480i 60Hz
- 1080p 50, 60Hz
- 1080i 50, 60Hz
- 720p 50,60 Hz
Dimensions
- Bezel width: 14.9 mm (Even bezel)
- Set dimensions (W x H x D): 1683.5 x 961.7 x 69.5mm(D@wall mount) / 91.8mm(D@handle) mm
- Set dimensions in inch (W x H x D): 66.28 x 37.86 x 2.74(@ wall mount)/ 3.61(@handle) inch
- Product weight: 37.5 kg
- Product weight (lb): 82.67 lb
- VESA Mount: 600 x 400 mm, M8
Convenience
- Keyboard control: Hidden, Lockable
- Network controllable: RS232, RJ45
- Signal loop through: RS232, IR Loopthrough
- Energy saving functions: Smart Power
- Remote control signal: Lockable
- Tiled Matrix: Up to 15 x 15
- Placement: Landscape (18/7), Portrait (18/7)
- Start-up: Switch on delay, Switch on status, Boot on source
- Start-up window: enable / disable Philips logo
- Ease of installation: Smart Insert
Power
- Mains power: 100 - 240V~, 50/60Hz
- Standby power consumption: <0.5W
- Power Saving Features: Smart Power
- Consumption (Max): 310 W
- Consumption (Typical): 160 W
- Energy Label Class: G
Operating conditions
- Altitude: 0 ~ 3000 m
- Temperature range (operation): 0 ~ 40 °C
- Temperature range (storage): -20 ~ 60 °C
- MTBF: 50,000 hour(s)
- Humidity range (operation)[RH]: 20 ~ 80% RH (No condensation)
- Humidity range (storage) [RH]: 5 ~ 95% RH (No condensation)
Sound
- Built-in speakers: 2 x 10W RMS
Accessories
- Included accessories: AC Power Cord, RS232 cable, Remote Control, Batteries for remote control, Quick start guide
- Included Accessories: IR sensor cable (1.8 m) (x1), RS232 daisy-chain cable, M3 screw (X1), M4 Screw (x1), Philips logo (x1), USB Cover (x1)
Multimedia Applications
- USB Playback Video: MPEG, H.264, H.263, H.265
- USB Playback Picture: BMP, JPEG, PNG
- USB Playback Audio: AAC, HEAAC, MPEG
Miscellaneous
- Warranty: 3-year warranty
- On-Screen Display Languages: Simplified Chinese, Traditional Chinese, English, French, German, Italian, Polish, Russian, Spanish, Turkish, Japanese, Arabic
- Regulatory approvals: CE, CB, BSMI, CU, EPA, ETL, FCC, Class A, PSB, VCCI
Internal Player
- CPU: Dual-core cortex A53 1.1G Hz, Dual core cortex A73 1.15G Hz
- GPU: ARM Mali G51
- Memory: 2GB DDR3, 8GB
|
