AirLink® XR90 5G High-Performance Multi-Network Vehicle Router
5G High-Performance Multi-Network Vehicle Router for Transit, Rail and First Responder Fleets.
Downloads:
You have to
The supercharged AirLink XR90 is purpose-built for public safety and transit with
single/dual 5G cellular radios and dual independent 4x4 MIMO Wi-Fi 6. It supports complete device-to-cloud security and reduces your total cost of ownership with ALMS Out-of-Band management via built in LPWA network delivering zero touch configuration, reset to factory over the air and remote support regardless of the primary WAN connections. Utilising a cartridge-based design, enables long-term expandability and upgradability.
For detailed user configuration details pls sign up for "The Source" and access the Airlink OS page: https://source.sierrawireless.com/airlinkos/XR90/2.0/
Up to 2 Gbps DL/210 Mbps UL
Optional dual 5G cellular
LPWA exclusively for ALMS Out-of-Band Management
Dual independent 4x4 Wi-Fi 6 AP/STA up to 2.4Gbps
Support for 128 clients. WPA2/3 Enterprise. High output power 21 dBm (per chain)
All WAN/LAN interfaces use Sierra Cognitive Wireless and Data Path Acceleration Architecture
Single 5G: 4x RJ-45 Ethernet ports (1x 5Gbps, 3x 1Gbps)
Dual 5G: 5x RJ-45 Ethernet ports (1x 5Gbps, 4x 1Gbps)
Dual SIM Slots. Dual RS-232 serial on RJ-45
Aux Port (GPIO/CAN). USB 3.2 type-C port. Bluetooth 5.1 (future support)
All Sierra Wireless security features including secure boot and secure firmware update.
AAA: 802.1x/Radius authentication
Stateful firewall with port forwarding and DMZ
WPA2/3 Personal/Enterprise WLAN Encryption and FIPS 140-2
Safety: IECEE Certification Bodies Scheme (CB Scheme), UL 60950
Vehicle Usage: E-Mark (72/245/EEC, 2009/19/EC), ISO7637-2, SAE
J1455 (Shock & Vibration)
Environmental: RoHS2, REACH, WEEE
Rail Usage: EN50155 (Rolling Stock)
Single 5G: 220mm x 220mm x 53mm (8.66in x 8.66in x 2.08in)
Dual 5G: 268mm x 220mm x 53mm (10.55in x 8.66in x 2.08in)
