AiTRON-910EP/H 10.1” Industrial Fanless Panel PC with Intel Core Ultra
10.1" WXGA Intel Core Ultra 5/7 Platform Fanless Industrial Multitouch Panel PC
Key Features:
- 10.1” Industrial Grade Multitouch Panel PC
- Intel Core Ultra 5/7 Processor
- Support 1 x DDR5-5600MHz SO-DIMM
- IP66 Compliant Aluminium Narrow Bezel Design
- 7H Anti-scratch Projected Capacitive Multi-touch Screen
- Support High Brightness LCD (optional)
- Support Auto-Dimming(PB-49/50)(optional)
- Power Input: DC 9-36V
- Fanless Design
Description
Product Overview
The Aplex AiTRON-9E Series is a rugged industrial HMI panel PC range designed for automation, edge AI and smart factory applications. Powered by Intel Core Ultra 5 and Ultra 7 processors, the series combines high efficiency processing, integrated AI acceleration and industrial durability within a compact fanless platform. Featuring projected capacitive multitouch displays, wide voltage input and flexible expansion, the AiTRON-9E Series is suited to industrial control, machine interface and intelligent edge deployments.
Key Features
Intel Core Ultra Platform
-
Intel Core Ultra 5 and Ultra 7 processor options
-
Integrated AI acceleration for edge inference and intelligent applications
-
Supports DDR5 memory up to 48 GB
-
Designed for responsive multitasking and industrial workloads
Industrial Multitouch Display
-
Industrial-grade projected capacitive multitouch interface
-
7H anti-scratch touchscreen surface for durability
-
Standard and high-brightness display options available
-
Wide viewing angles for improved visibility in industrial environments
Rugged Fanless Construction
-
Fanless aluminium die casting chassis for silent operation
-
IP66-compliant front bezel for protection against dust and water
-
Designed for continuous operation in demanding environments
-
Suitable for factory automation and outdoor-facing installations
Flexible Expansion and Connectivity
-
Multiple M.2 slots for storage, WiFi, Bluetooth and LTE or 5G modules
-
Nano SIM slot for cellular connectivity integration
-
Dual 2.5GbE LAN ports for high-speed networking
-
USB, serial and display outputs for industrial peripherals and control systems
Wide Power and System Support
-
Wide DC 9 V to 36 V power input range
-
Supports Windows 10 IoT Enterprise, Windows 11 and Linux
-
TPM 2.0 onboard for enhanced system security
-
Watchdog timer and Wake on LAN support for remote management
Mounting and Integration
-
Supports panel mount and VESA mounting installation
-
Compact design for control cabinets and operator panels
-
HDMI and DisplayPort outputs supporting high-resolution displays
-
Suitable for machine control, HMI and intelligent edge applications
Applications and Use Cases
The AiTRON-9E Series is suitable for:
-
Industrial automation and machine control
-
Smart manufacturing and Industry 4.0 deployments
-
Edge AI and intelligent monitoring systems
-
Transportation and infrastructure applications
-
Industrial HMI and operator interface systems
Dimensions/Drawings
Download
More Information
| Brand | Aplex Technology Inc. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Specifications |
|
Ordering Information
AiTRON-910EP
10.1" WXGA fanless HMI barebone with Intel Core Ultra 5/7, 1 x DDR5 slot, 1 x M.2 M-key slot, 1 x M.2 E-key slot, 1 x M.2 B-key slot, Projected Capacitive touch, 9~36V DC input with adapter, Aluminum chassis.
AiTRON-910EPH
10.1" WXGA High Brightness fanless HMI barebone with Intel Core Ultra 5/7, 1 x DDR5 slot, 1 x M.2 M-key slot, 1 x M.2 E-key slot, 1 x M.2 B-key slot, Projected Capacitive touch, 9~36V DC input with adapter, Aluminium chassis.
