APC-32WR6 32" Ultra Slim Panel PC with Rockchip RK3576S
View larger image
APC-32WR6 32" Ultra Slim Panel PC with Rockchip RK3576S
32" Ultra Slim Panel PC with Rockchip RK3576S Quad core & Android 14
Key Features:
32" 1920 x 1080 Slim Panel PC with PCAP touch Rockchip RK3576S Quad core cortex A53+Quad core cortex A72 4GB LPDDR5/ 64GB eMMC Fanless operation from 0°C ~ 40°C DC 12V and support Powered LAN (802.3bt) Support Android 14 with Google EDLA
Description
Product Overview
The Avalue APC-32WR6 is a 32-inch industrial panel PC designed for smart facilities, automation systems and large interactive display environments. It features a slim fanless design with an ARM platform and a full HD projected capacitive touchscreen, allowing reliable operation in applications that require continuous uptime and minimal maintenance. With Android operating system support and integrated connectivity options, the APC-32WR6 is suited for industrial monitoring, kiosks, digital signage and smart building control interfaces.
Key Features
Efficient and Stable Performance
Rockchip RK3576S processor with multi-core architecture
Onboard memory and eMMC storage are designed for stable system operation
Integrated graphics supporting modern visual applications
Designed to support Android environments for flexible deployment
Display and Touch Interface
32-inch IPS display with 1920 × 1080 resolution
Projected capacitive multi-touch panel supporting interactive applications
Wide viewing angles for clear visibility across large display areas
Full HD display suited for dashboards, signage and control systems
Connectivity and Integration
Gigabit Ethernet for reliable network connectivity
USB ports for peripherals and external devices
HDMI input for external video sources
Optional wireless connectivity, including WiFi and Bluetooth
Optional NFC and camera support for interactive deployments
Rugged Fanless Design
Fanless architecture designed for silent operation and reduced maintenance
Slim enclosure suitable for wall mounting or panel installation
Designed for reliable operation in industrial and commercial environments
DC power input suitable for commercial installations
Application Ready
The APC-32WR6 is suitable for:
Industrial automation interfaces
Smart building management systems
Digital signage and information displays
Interactive kiosks and self-service terminals
Monitoring dashboards in facilities and control rooms
More Information
Brand
Avalue Technology Inc
Specifications
Processor
Rockchip RK3576S (Quad Cortex-A53 + Quad Cortex-A72)
System Memory
Onboard 4GB LPDDR5
Storage
Onboard 64GB eMMC
Graphics
Mali-G52 MC3 GPU, supports OpenGL ES 1.1 / 2.0 / 3.2, Vulkan 1.2, OpenCL 2.1
Speaker Output
2 × 4Ω 5W
Ethernet Interface
10 / 100 / 1000 Base-Tx GbE
DC Input Voltage
+12V
DC Connector
DC Jack
Adapter
Input: 100–240VAC, 50–60Hz
Output: 60W AC-DC adapter (12V @ 5A)
Operating System
Android 14
Display Size
32 inch
Panel Type
IPS
Resolution
1920 × 1080
Brightness
300 cd/m²
Contrast Ratio
1000:1
Viewing Angle
89° (U / D / L / R)
Response Time
8 ms
Backlight
ELED
Touchscreen
Projective capacitive multi-touch (up to 10 points)
USB Ports
1 × USB 3.0
1 × USB 2.0
1 × USB Type-C (full function except charging and DP)
LAN Port
1 × RJ45
HDMI
1 × HDMI-in
DC Input Port
1 × DC Jack
Buttons
Power / Volume Up / Volume Down
NFC
Supports 13.56MHz, ISO/IEC 18092, ISO/IEC 21481, ISO/IEC 14443 A/B, ISO/IEC 15693, JIS X 6319-4, MIFARE
Camera
1 × MIPI 8.0MP camera
Wi-Fi
Optional Wi-Fi 802.11b/g/n/a/ac/ax
Bluetooth
Optional Bluetooth 5.4
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
−20°C to 60°C (−4°F to 140°F)
Operating Humidity
20–80% RH
Dimensions (W × L × H)
735.6 × 436.2 × 36.5 mm
Weight
7.7 kg
Mounting
Wall mount bracket included
VESA Mount
100 × 100 mm
Power Options
DC 12V or Powered LAN (802.3bt)
Power Mode
AT / ATX (AT default)
Cooling
Fanless
Construction
Plastic ABS
Packing List
1 × APC-32WR6
1 × AC/DC 60W Adapter (12V / 5A)
1 × Power Cord
1 × USB Cable (Type-A to Type-C)
1 × Wall mount bracket
5 × KA4.0 × 3 mm screws with wall plug
2 × M4.0 × 46 mm screws
4 × EVA cotton pads
1 × Spirit Level
