ATC3750-IP7-WI8MR NVIDIA Jetson AGX Orin Edge AI Computer
High Performance NVIDIA Jetson AGX Orin Edge AI Computer for Railway Applications
Key Features:
- Built-in NVIDIA® Jetson AGX Orin™ SOM, up to 200/275 TOPS (INT8)
- Designed to be IP67-rated, rugged, and compact
- 8 MIPI/GMSL2 & 2.5GbE (X-coded) for MIPI CAM/IP CAM/LiDAR
- HEVC/H.265 hardware DECODE, supporting up to 7 x 4K30
- Wide range operating temperature of -25°C~70°C
- Ultra-speed PCIe 4.0 x4 NVMe SSD for data integrity
- Expansible for GNSS, LTE/5G NR & Wi-Fi 5/6
- 24~110VDC w/ isolation, ignition control & OCP/OVP
- NEXCOM Acceleration Linux (NAL) integrated w/ JetPack 6.1
- Military standard of MIL-STD-810H for anti-vibration/shock
- CE/FCC, UKCA, EN50155 (EN55011, EN50121-3-2, EN61373, OT3), EN45545-2 certified
Description
AI has become an essential component of automated railway vehicle technologies. With its built-in high-performance NVIDIA Jetson AGX Orin System-on-Module (SOM), the ATC 3750-IP7-WI8MR is capable of delivering up to 200/275 TOPS workload on Artificial Intelligence (AI) processing and inference. This makes it ideal for supporting applications such as railway safety assurance, operation optimization, maintenance management, and self-driving trains.
Thanks to NEXCOM's excellent thermal solutions, the ATC 3750-IP7-WI8MR can function efficiently and maintain its defined TDP (15W~60W) in harsh environments without the need for a fan kit. This enables it to achieve 200/275 TOPS workload performance even in extreme conditions.
The ATC 3750-IP7-WI8MR is a rugged, compact-sized railway AI-powered computer that is IP67-rated. It features 24~110VDC (power isolation) with IGN control, 8 MIPI/GMSL2 for accessing MIPI CAM/LiDAR sensors, and rich peripheral ports such as GbE/2.5GbE, USB3.2, isolation CANBus, RS232, Console, DI/DO, OTG, and HDMI. With the installation of 5G NR, Wi-Fi 5/6 modules, the ATC 3750-IP7-WI8MR can collaborate with CPS for AI model re-training, making it suitable for deployment in sophisticated applications such as railway vehicle relevant applications.
The ATC 3750-IP7-WI8MR can operate at a wide temperature range of -25~70°C and meet the MIL-STD-810H military standard for anti-vibration and shock, even in harsh environments. For regulation, the ATC 3750-IP7-WI8MR is certified by CE/FCC Class A, UKCA, EN50155, and EN45545-2.
Download
More Information
| Brand | Nexcom | ||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Specifications |
|
Ordering Information
ATC 3750-IP7-8M (P/N: 10AT0375004X0)
NVIDIA® Jetson AGX Orin™ SOM, 32GB LPDDR5, 64GB eMMC, GbE, 2.5GbE, 2/2 x USB 3.2/2.0, 1 x RS232/422/485, 1 x RS232, OTG/Console, 9~36VDC/24VDC Rail
ATC 3750-IP7-8M-64 (P/N: 10AT0375005X0)
NVIDIA® Jetson AGX Orin™ SOM, 64GB LPDDR5, 64GB eMMC, GbE, 2.5GbE, 2/2 x USB 3.2/2.0, 1 x RS232/422/485, 1 x RS232, OTG/Console, 9~36VDC/24VDC Rail
