DrivePro Body 20

End of Life
SKU: DrivePro Body 20

DrivePro Body 20



WiFi

IPX4

Datasheet

Description

The DrivePro Body 20 features a 160° field of view and f/2.8 aperture lens, 1080p Full HD and built-in Wi-Fi. The body cam is suitable for military, law enforcement, and private security.

Download

Data Sheet

More Information

Specifications
Dimensions 88.4 mm x 52.2 mm x 19.4 mm (3.48" x 2.06" x 0.76")
Weight 88 g (3.10 oz)

Interface
USB Type
  • 3.5mm plug to USB Type A
Connection Interface
  • USB 2.0

Storage
Capacity
  • 32GB internal memory

Hardware
Viewing Angle 160° (diagonal)
Aperture F/2.8

Power
Battery Life (Max.) 3.5 hour(s)
Power Supply (Max.)
  • Input: AC 100V-240V, 50-60Hz, 0.4A
  • Output: DC 5V / 2A
Note
  • Battery life and charge cycles vary by use, network settings such as Bluetooth and Wi-Fi, and other environmental factors; actual results will vary.

Format
Resolution
  • Full HD 1080P
Frame Rate 30 fps
Video Format
  • MOV (H.264)

Operating Environment
Operating Temperature -20°C (-4°F) ~ 65°C (149°F)
Storage Temperature -25°C (-13°F) ~ 70°C (158°F)
IP Rating IPX4

Warranty
Certificate
  • CE/
  • FCC/
  • BSMI/
  • NCC/
  • MIC/
  • KC
Warranty
  • Two-year Limited Warranty
Warranty Policy
  • Please visit https://www.transcend-info.com/Warranty for more information about the Transcend Warranty Policy.
  • Drop test is based on U.S. military drop-test standards MIL-STD-810G 516.6, and performed in non-operating state. This does not guarantee the invulnerability of this product under any circumstances. More information about Transcend's MIL-STD test can be found at https://www.transcend-info.com/Support/FAQ-1045.

Package
Package Contents
  • Full unit/
  • 3.5mm to USB cable/
  • Adapter/
  • 360° rotating clip/
  • Velcro holder

System Requirement
Operating System
  • Microsoft Windows 7
  • Microsoft Windows 8
  • Microsoft Windows 10
