PCIe to four isolated PoE/PoE+ Module

Enquire Now
Enquire about this product:

PCIe to four isolated PoE/PoE+ Module


·         Supports four isolated GbE LAN ports

·         Four independent PSE channels

·         Complies with IEEE 802.3af, up to 15.4W at 48V per PoE port

·         Complies with IEEE 802.3at, up to 25.5W at 54V per PoE port

·         Supports power input 12V~24V from 6pin PCIE-ATX

·         Total power budget is 75W for 4 output PoE ports with maximum 25.5W per port

·         Complies with EN61000-4-5 2kV surge protection

·         Complies with IEC 60950-1:2005 + A1: 2009 + A2:2013 2kV HiPOT protection

·         30μ" golden finger, 3-year warranty

This product is listed in Industrial Automation, Mining, Transport, Industrial Computing, Embedded Peripherals
Module Type PCIe to four isolated PoE/PoE+ Module
Function PoE
Form Factor Standard PCIe
Output I/F PoE/PoE+ x 4
Output connector RJ45 x 4
TDP 8.58W (12V x 715mA From PCIe bus)
1.75W (3.3V x 530mA From PCIe bus)
Dimensions (W x L x H/mm) 169.55 x 111.15 x 19.6
Temperature Operation: STD temp: 0°~70°C; W/T temp: -40°C ~ +85°C
Storage: -55°C ~ +95°C
Environment Vibration: 5G @7~2000Hz
Shock: 50G @ 0.5ms
Notes Please download driver from MyInnodisk website.
Windows: XP(32bit), 7(32/64bit), 8/8.1(32/64 bit), 10(32/64bit)
Linux: kernel 2.4 series, 2.6.x and 3.x version.
