FABS-112P - 12.1" Stainless Steel Display
SKU:
FABS-112P - 12.1" Stainless Steel Display
12.1” Flat Front Panel IP66 Stainless Chassis Display
Description
Stainless steel front bezel Display
Flat front panel touch screen
Projected Capacitive Touch or Glass (Option)
Wide range DC 9~36V power input
IP66 compliant front panel / IP69K for option
VGA, DP, DVI/HDMI input
OSD on the rear side
System Power LED light
High brightness LCD for option
Download
More Information
| Brand | Aplex Technology Inc. |
|---|---|
| Specifications |
IO Port
VGA1
DVI1 x DVI-D
HDMI1
DP1
OSD Control MembraneOSD at rear side On board controller, extendable key pad from connector
Others1 x USB type B for touch control, 1 x Audio line-in phone jack, Optional I/O: 1 x Speaker
Power1 x 3-pin terminal block for DC 9~36V power input
Display
LCD Size12.1” TFT LCD
Max. resolution800 x 600, 1024 x 768
Max. color16.2M
Luminance(cd/m²)450, 500
Viewangle(H°/V°)178(H) / 178(V), 160(H) / 140(V)
Contrast1500:1, 700:1
Backlight lifetime(hrs)50,000 hrs, 30,000 hrs
Touch Screen(Option)
Touch TypeProjected Capacitive Touch
InterfaceUSB Interface
Light transmission(%)Over 90%
Power
Power inputDC 9~36V
Mechanical
ConstructionAluminum die-casting chassis
IP ratingIP66 compliant front panel / IP69K(option)
MountingPanel mount / VESA mount 100 x 100
Dimension(mm)331 x 257 x 52 mm
Environment
Operatiing temperature(°C)0~50°C
Storage temperature(°C)-30~70˚C
Storage humidity10 to 90% @ 40°C, Non-condensing
CertificationCE/FCC, Class A
|
