D67 4K Dual Display Media Player
End of Life
In stock
SKU:
D67
Brand: Giada Technology Inc.
Digital Signage Player, i3-7100U / i5-7200 CPU
Downloads:
Enquire Now
Enquire about this product
Book size Kabylake high end signage player, Intel 7th generation core processor
· Intel 7th generation core processor
· 2 x SO-DIMM DDR3L/DDR4 Memory,Up to 32GB
· 1 x DP,1 x HDMI, Supporting 4K Display
· 1 x 2.5” SATA, 1 x mSATA, 1 x M.2 (2242/2280)
· 3 x USB 3.0, 3 x USB2.0, 1 x RS232
· 1 x RJ45,1 x Mini-PCIe for WiFi/BT/3G/4G, 1 x SIM Slot
| D67 | ||
| Processor | CPU | Intel®Pentium 4415U/Core i3-7100U/Core i5-7200U |
| Frequency | 2.30GHz / 2.40GHz / 2.50GHz(Up to 3.10GHz) | |
| BIOS | AMI Source Code | |
| Chipset | SOC | |
| Memory | Type | DDR4/DDR3L |
| Socket | 2 x SO-DIMM | |
| Max Size | 32GB | |
| Graphics | GPU | Intel® HD Graphics 620 |
| Graphic Engine | Direct3D 2015, OpenGL 4.5, OpenCL 2.1 | |
| DP | 1 x DP (Max.4096 x 2304 @60Hz) | |
| HDMI | 1 x HDMI (Max.3840x2160 @30Hz) | |
| Network | Controller | Realtek 8111H Gigabit Ethernet |
| Interface | 1 x RJ45 | |
| I/O | USB | 3 x USB 3.0,3 x USB 2.0 |
| Serial Port | 1 x RS232 | |
| Audio | 1 x AUDIO-OUT, 1 x MIC-IN | |
| Mini-PCIe1# | 1 x Full-size Mini-PCIe for mSATA | |
| Mini-PCIe2# | 1 x Full-size Mini-PCIe for WiFi/BT/3G/4G | |
| M.2(2230) | 1 x M.2(2242/2280) for SSD | |
| SIM | 1 x SIM Slot | |
| Storage | SATA | 1 x 2.5"SATA |
| mSATA | 1 x Full-size mSATA | |
| M.2 | 1 x M.2(2242/2280) for SSD | |
| JAHC Tech | WatchDog Timer | 0~255 Second Time Out Support |
| Auto Power On | Power Activated Automatically Start | |
| Remote Control | By IR Controller for Power On | |
| RTC | Set Up Independently Every day, A Week as a Cycle | |
| Operation System | Windows | Windows 10（64-Bit） |
| Linux | Supported | |
| Power | Power Type | DC-IN |
| Input Voltage | 19V / 3.42A | |
| Mechanical | Dimensions (W × D × H) | 189.6mm x 148.3mm x 26mm（7.46"x 5.84"x 1.02"） |
| Construction | Metal | |
| Mounting | Desk/Wall Mounting and VESA Mounting Kit (JZ183) | |
| Color | Black | |
| Environment | Operating Temperature | 0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow |
| Relative Humidity | 95%@40℃ (non-condensing) | |
| Certification | Certification | CE, FCC Class B, CCC |
