6th Gen Intel® Core™ i5-6300U, 2-Core, 2.4GHz processor
System Chipset
Integrated in Intel ® Skylake ULT Processor
System Memory
One 204-pin SODIMM Socket Up to 16GB DDR4 2133 SDRAM
TPM
Infineon TPM 2.0
Graphics Controller
Intel® HD Graphics 520
Expansion
Expansion
1 x mini PCIe full size (support half size) Auto switch for mSATA or Mini PCIe, USB 1 x mini PCIe full size (support half size) Auto switch for mSATA or Mini PCIe, USB (by IET module)
Storage
HDD/ SSD
2.5" SSD
Other Storage Device
mSATA (optional)
Panel
LCD Size
24"
LCD Panel
24" TFT-LCD
Resolution
1920 x 1200 WUXGA
Pixel pitch
270 x 270
Luminance
300 cd/m²
Contrast ratio
1000
Viewing angle
178/178 °
Backlight
LED
Touch Type
Projective Capacitive
Touch Light Transmission
89% AR Coating
Touch Controller
USB interface, EETI
DICOM compliant
DIN 6868157
I/O
USB
4 x USB3.0, 4 x USB2.0 by pin header 2 x USB2.0 (Isolated 5KV), 1 x USB2.0 by pin header on IET module
COM Port
1 x RS-232/422/485, 1 x RS-232 1 x RS-232 (Isolated 5KV), 1x RS-232/422/485 (Isolated 5KV) on IET module
HDMI
HDMI Video out on IET module
Reading light bar
LED Type
Display
Chipset
Intel® HD Graphics 520
Resolution
HDMI: 3840 x 2160 @ 24Hz (optional by IET module)
Audio
Chipset
Realtek ALC892
Audio Interface
Audio out and Mic in
Speaker Output
2 x 0.5W
Ethernet
LAN Port
1 x Intel ® I219LM Gigabit Ethernet 1 x Intel ® I211AT Gigabit Ethernet 2 x Intel ® I210AT Gigabit Ethernet (Isolated 5KV) on IET module
DC In/Out Characteristics
Power Type
AT/ATX
Input Voltage Range
100~240 Vac, 1.5~0.75A, 50~60Hz
Output Voltage Range
+24Vdc, 3.75A max. (90W)
DC In / Out Connector
Input Power Connector
4 pin DC Jack
Mechanical & Environmental
Dimensions(W x L x D)
573.8mm x 387.8 mm x 62.5 mm
Operating Temperature
0 ~ 35° C (32 ~ 95° F)
Storage Temperature
-20 ~ 60° C (4 ~ 140° F)
Weight
10kg
Construction
Plastic
Surface
Anti-Microbial Finishing
IP Rating
Front Panel IP65 Whole Unit IPX1
Vibration Test
With SSD/mSATA: 1.5Grms, IEC 60068-2-64, Radom, 5~500Hz, 30min/axis
Shock Test
With SSD/mSATA: 10Grms, IEC 60068-2-27, Half sine, 11ms
Relative Humidity
0%~90% Relative Humidity, Non-condensing
Certifications
