HSD452T & HSD452T-I SATA III, Half-Slim SSD
The HSD452T Half-Slim SSDs deliver outstanding transfer speeds in a compact form factor to ensure the utmost quality and performance, best suited to read-heavy applications and space-limited mobile devices such as industrial control systems, medical equipment, mobile devices, and POS terminals.
Please fill in your details below, we will get back to you as soon as possible
DRAM Cache embedded
Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
Wide-temperature model available: promised operational reliability in a wide temperature range (from -40℃ to 85℃)
Advanced Global Wear-Leveling and Block management for reliability
Advanced Garbage Collection
Security Command
Built-in LDPC ECC (Error Correction Code) functionality
Enhanced S.M.A.R.T. function for durability
Compliant with RoHS 2.0 standards
Power-saving DevSleep (Device Sleep) mode (optional)
Appearance |
|
| Dimensions | 54.0 mm x 39.8 mm x 4 mm (2.13" x 1.57" x 0.15") |
|---|---|
| Weight | 9 g (0.32 oz) |
| mSATA Type | MO-297 |
| Pin Count | 7+15 pin |
| Form Factor |
|
Interface |
|
| Bus Interface |
|
Storage |
|
| Flash Type |
|
| Capacity |
|
Operating Environment |
|
| Operating Voltage |
|
| Operating Temperature |
|
| Storage Temperature | -40°C (-40°F) ~ 85°C (185°F) |
| Humidity | 5% ~ 95% |
| Shock |
|
| Vibration (Operating) | 20 G (peak-to-peak), 7 Hz ~ 2000 Hz (frequency) |
Power |
|
| Power Consumption (Operation) | 2.7 watt(s) |
| Power Consumption (Sleep) | 0.6 watt(s) |
Performance |
|
| Sequential Read/Write (CrystalDiskMark, max.) | Read: 560 MB/s Write: 520 MB/s |
| 4K Random Read/Write (IOmeter, max.) | Read: 90,000 IOPS Write: 85,000 IOPS |
| Mean Time Between Failures (MTBF) | 3,000,000 hour(s) |
| Terabytes Written (Max.) | 880 TBW |
| Drive Writes Per Day (DWPD) | 1.61 (3 yrs) |
| Note |
|
Warranty |
|
| Certificate |
|
| Warranty |
|
| Warranty Policy |
|
