HSD470T Half-Slim SSDs

In stock
Brand: Transcend

SATA III 6Gb/s interface, a powerful controller, and state-of-the-art 112-layer 3D NAND flash


Enquire Now
Enquire about this product

Transcend's HSD470T Half-Slim SSDs have an extended operating temperature range of -20°C to 75°C, a powerful controller, a state-of-the-art 112-layer 3D NAND flash, Corner Bond technology for enhanced durability, built-in DRAM cache for quick access, and an endurance rating of 3K Program/Erase cycles for dependable operation. HSD470T SSDs, which adhere to the MO-297 standard established by JEDEC, go through rigorous reliability testing to guarantee the highest quality and performance. These SSDs are best suited for read-heavy applications and space-constrained mobile devices, such as industrial control systems, medical equipment, mobile devices, and POS terminals.

Key Features:

  • Compliant with RoHS 2.0 standards
  • Compliant with JEDEC MO-297
  • DDR3 DRAM Cache embedded
  • Key components fortified by default with Corner Bond technology
  • Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
  • Dynamic thermal throttling
  • Built-in LDPC ECC (Error Correction Code) functionality
  • Advanced Global Wear-Leveling and Block management for reliability
  • Advanced Garbage Collection
  • NCQ command for better performance

This product is listed in Industries, Partners, Digital Signage, Industrial Automation, Gaming, Mining, Medical, Transport, Transcend
Appearance Dimensions 54 mm x 39.8 mm x 4 mm (2.13" x 1.57" x 0.15")
Weight 9 g (0.32 oz)
Pin Count 7+15 pin
Form Factor Half-slim (MO-297)
Interface Bus Interface SATA III 6Gb/s
Storage Flash Type 112-layer 3D NAND flash
Capacity 128 GB / 256 GB / 512 GB / 1 TB
Operating Environment Operating Voltage 5V±5%
Operating Temperature Extended Temp.
-20°C (-4°F) ~ 75°C (167°F)
Storage Temperature -55°C (-67°F) ~ 85°C (185°F)
Humidity 5% ~ 95%
Shock 1500 G, 0.5 ms, 3 axis
Vibration (Operating) 20 G (peak-to-peak), 7 Hz ~ 2,000 Hz (frequency)
Power Power Consumption (Operation) 4 watt(s)
Power Consumption (Sleep) 1.4 watt(s)
Performance Sequential Read/Write (CrystalDiskMark) Read: up to 560 MB/s
Write: up to 520 MB/s
4K Random Read/Write (IOmeter) Read: up to 90,000 IOPS
Write: up to 85,000 IOPS
Mean Time Between Failures (MTBF) 3,000,000 hour(s)
Terabytes Written (TBW) up to 2420 TBW
Drive Writes Per Day (DWPD) 2.16 (3 yrs)
