IES-1142P - 16 port unmanaged switch
IES-1142P - 16 port unmanaged switch
14x10/100Base-T(X) and 2x100Base-FX in SFP ports. IES-1142P supports redundant power inputs, wide operating temperature range from -40°Cto70°C.
Description
- Dual redundant DC power inputs of terminal block
- Provide 14x10/100Base-T(X) and 2x100Base-FX SFP ports
- Support auto-negotiation and auto-MDI/MDI-X
- Support store and forward transmission
- Support flow control
- Rigid IP-30 housing design
- DIN-Rail mounting enabled
More Information
|
Specifications |
| Physical Ports |
|
|
10/100Base-T(X) Ports in RJ45 Auto MDI/MDIX
|
14 |
|
100Base-FX SFP Ports
|
2 |
| Technology |
|
| Ethernet Standards |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3x for Flow control
|
| MAC Table |
4096 |
| Processing |
Store-and-Forward |
| LED Indicators |
|
| Power Indicator |
Green : Power LED x 3 |
| 10/100Base-T(X) RJ45 Port Indicator |
Green for port Link/Act. Amber for speed indicator – Amber for 100Mbps, Off-light for 10Mbps |
| 100Base-FX SFP Port Indicator |
Green for port Link/Act |
| Power |
|
| Redundant Input Power |
Dual DC inputs. 12~48VDC on 6-pin terminal block |
| Power Consumption (Typ.) |
10 Watts |
| Overload Current Protection |
Present |
| Reverse Polarity Protection |
Present on terminal block |
| Physical Characteristics |
|
| Enclosure |
IP-30 |
| Dimensions (W x D x H) |
74 x 140 x 170 mm (2.91 x 5.51 x 6.69 inch) |
| Weight (g) |
1120 g |
| Environmental |
|
| Storage Temperature |
-40 to 85oC (-40 to 185oF) |
| Operating Temperature |
-40 to 70°C (-40 to 158oF) |
| Operating Humidity |
5% to 95% Non-condensing |
| Regulatory Approvals |
|
| EMI |
FCC Part 15, CISPR (EN55022) class A |
| EMS |
IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 |
| Shock |
IEC60068-2-27 |
| Free Fall |
IEC60068-2-32 |
| Vibration |
IEC60068-2-6 |
| Safety |
EN60950-1 |
| MTBF (Hours) |
7198000.9498 |
| Warranty |
5 years |
|
