IES-162FX-L Series - 8 port unmanaged switch
IES-162FX-L Series - 8 port unmanaged switch
6x10/100Base-T(X) with 2x100Base-FX port wide operating temperature range from -40°C to 70°C.
Description
- Support 6x10/100Base-T(X) and 2x100Base-FX single/multi-mode fiber ports
- Support auto-negotiation and auto-MDI/MDI-X
- Support store and forward transmission
- Support flow control
- Support broadcast storm protection
- Compact size for easily installation
- Support operating temperature from -20 to 60oC
- Rigid IP-30 housing design
- DIN-Rail and wall mounting enabled
More Information
|
Specifications |
| Physical Ports |
|
|
10/100 Base-T(X) Ports in RJ45 Auto MDI/MDIX
|
6 |
| Fiber Ports Number |
2 |
2 |
| Fiber Ports standard |
100Base-FX |
100Base-FX |
| Fiber Mode |
Multi-mode |
Single-mode |
| Fiber Diameter (μm) |
62.5/125 μm
50/125 μm
|
9/125 μm |
| Fiber Optical Connector |
SC |
SC |
| Typical Distance (Km) |
2 Km |
30 Km |
| Wavelength (nm) |
1310 nm |
1310 nm |
| Max. Output Optical Power(dbm) |
-14 dbm |
-8 dbm |
| Min. Output Optical Power (dbm) |
-23.5 dbm |
-15 dbm |
| Max. Input Optical Power(Saturation) |
0 dbm |
0 dbm |
| Min. Input Optical Power(Sensitivity) |
-31 dbm |
-34 dbm |
| Link Budget (db) |
7.5 db |
19 db |
| Technology |
|
| Ethernet Standards |
IEEE 802.3 for 10Base-T,
IEEE 802.3u for 100Base-T(X) and 100Base-FX,
IEEE 802.3x for Flow control
|
| MAC Table |
1024 MAC addresses |
| Priority Queues |
448Kbits |
| LED Indicators |
|
| Power Indicator |
Green : Power LED x 1 |
| 10/100Base-T(X) RJ45 Port Indicator |
Green for port Link/Act. Amber for speed indicator – Amber for 100Mbps, off-light for 10Mbps |
| 100Base-FX Fiber Port Indicator |
Green for port Link/Act. |
| Power |
|
| Power Input |
10~30VDC on 3-pin terminal block. |
| Power Consumption (Typ.) |
3.6 watts max. |
| Overload Current Protection |
Present |
| Reverse Polarity Protection |
Present |
| Physical Characteristics |
|
| Enclosure |
IP-30 |
| Dimensions (W x D x H) |
41 x 83.98 x 115 mm (1.61 x 3.31 x 4.53 inch) |
| Weight (g) |
328 g |
| Environmental |
|
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
| Operating Temperature |
-20 to 60°C (-4 to 140oF) |
| Operating Humidity |
5% to 95% Non-condensing |
| Regulatory Approvals |
|
| EMI |
FCC Part 15, CISPR (EN55022) class A |
| EMS |
IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 |
| Shock |
IEC60068-2-27 |
| Free Fall |
IEC60068-2-32 |
| Vibration |
IEC60068-2-6 |
| Safety |
EN60950-1 |
| Warranty |
5 years |
|
