INJ-101GT++-90W - 1 port PoE injector

In stock

Industrial 1-port Gigabit High Power PoE++ Injector, 9 to 57VDC

Enquire Now
Enquire about this product:

·         PoE++ Injector for 1x10/100/1000Base-T(X)

·         Fully compliant with IEEE802.3at/802.3af standard

·         Auto protection for Over Voltage Power Input and over current output

·         Supports totally Power Output up to 90 Watts for all ports usage.

·         Support wide range power input from 9 to 57VDC

·         Provided DIP switch configurator for PoE mode management

·         High reliability and rigid IP-30 housing

·         DIN-Rail and Wall Mount Design

This product is listed in Ethernet Switches

ORing Injector Model INJ-101GT++-90W-24V
Physical Ports
RJ-45 Ethernet Port Input 1
RJ-45 Ethernet Port with P.S.E.
Operating Voltage
Input Voltage 9 ~ 57 VDC on 4-pin terminal block
LED Indicators
Power Indicator
PWR: 1 x LED
Green On: Power is on and functioning Normally.
PoE Indicators
1 x LED
Blue On: PoE Device Link
Off : None PoE Device Detected
Blink (Blue) : Overload present
DIP Switch
DIP Switch 1/2
DIP Switch 1/2 (OFF): PoE P.S.E set to master and Asyncronize mode.
DIP Switch 1/2 (ON) : PoE P.S.E set to Syncronize mode(default)
Input Power 9 ~ 57 VDC on 4-pin terminal block
Power Consumption 1 Watts (Not include PD’s device)
PoE Power Budget 30Watt at 9~24VDC, 90Watt at 24~57VDC
Short Circuit Protection Present
Over Load Protection Present
Physical Characteristic
Enclosure IP-30
Dimension (W x D x H) 41(W)x70(D)x95(H)mm (1.03 x 2.76 x 3.74 inch)
Weight (g) 318g
Storage Temperature -40 to 85
oC (-40 to 185oF)
Operating Temperature -40 to 75
oC (-40 to 167oF)
Operating Humidity 5% to 95% Non-condensing
Regulatory Approvals
EMC CE EMC (EN55024,EN 55032), FCC Part 15 B
EMI EN55032, CISPR 32, EN61000-3-2, EN61000-3-3, FCC Part 15 B class A
EN55024 (IEC/EN 61000-4-2 (ESD), IEC/EN 61000-4-3 (RS), IEC/EN 61000-4-4 (EFT),
IEC/EN61000-4-5 (Surge), IEC/EN 61000-4-6 (CS), IEC/EN 61000-4-8 (PFMF), IEC/EN 61000-4-11 (DIP))
Shock IEC60068-2-27
Free Fall IEC60068-2-31
Vibration IEC60068-2-6
Safety EN60950-1
MTBF 2067004hrs
Warranty 5 years
