MANO300 Mini-ITX SBC Celeron N3160 SoC, VGA/HDMI/LVDS, USB 3.0, Mini PCIe, mSATA

In stock
SKU:
MANO300VHGGA
Brand: Axiomtek

Category: Single Board Computers

Mini-ITX SBC with Intel® Celeron® Processor N3160 (up to 2.24 GHz) SoC, VGA/HDMI/LVDS, USB 3.0, Mini PCIe Card, mSATA and HD Audio


Enquire Now
Enquire about this product:

Intel® Celeron® processor N3160 2.24 GHz (Braswell)

2 DDR3L-1600 SO-DIMM, up to 8GB

PCI Express Mini Card and PCIe x1 slot

4 USB 3.0 and 2 USB 2.0 ports

1 SATA-600, 1 mSATA and 1 SDXC

6 COM ports

12 VDC and STD ATX

VGA,HDMI and LVDS with triple-view supported


This product is listed in Digital Signage, Industrial Automation, Mining, Transport, Axiomtek, Embedded Boards
CPU
  • Intel® Celeron® processor N3160 up to 2.24 GHz
Chipset
  • SoC integrated
System Memory
  • 2 x 204-pin SO-DIMM dual channel DDR3L-1600, up 8 GB
BIOS
  • AMI
COM
  • 2 x RS-232/422/485
  • 4 x RS-232 (one with +5/+12V)
USB
  • 2 x USB 2.0 (Internal)
  • 4 x USB 3.0
Ethernet
  • 2 x 10/100/1000 Mbps (Realtek RTL8111F)
Display
  • 1 x VGA
  • 1 x HDMI
  • 1 x LVDS
Digital I/O
  • 8 channels programmable
Audio
  • Mic-in/Line-out
Storage
  • 1 x SATA-600
  • 1 x mSATA
Expansion
  • 1 x PCIe x1
  • 1 x PCI Express Mini Card
  • 1 x SIM card slot
Others
  • 1 x PS/2 keyboard & mouse
Battery
  • Lithium 3 V/ 220 mAH
Power Input
  • 12VDC or STD ATX
Watchdog Timer
  • 255 levels, 1 ~ 255 sec.
Hardware Monitoring
  • N/A
Operating Temperature
  • 0°C ~ +60°C (+32°F ~ +140°F)
Relative Humidity
  • 10% ~ 95% relative humidity, non-condensing
Dimensions
  • 170 x 170 mm
Board Thickness
  • 1.6 mm
Certifications
  • CE
