NDiS V1100 Fanless Embedded Computer 11th Gen Core

In stock
NDiS V1100 Fanless Embedded Computer 11th Gen Core
Brand: Nexcom

Fanless Embedded Computer Powered by 11th Gen Intel Core Processor

Enquire Now

Please fill in your details below, we will get back to you as soon as possible

The NDiS V1100 digital signage player can drive extremely rich multimedia content thanks to its 11th Gen Intel Core processor. The platform provides powerful graphics with captivating visuals for stimulating 4K content creation and media playback thanks to Intel processors' low power consumption and new Intel Iris Xe graphics. Further, the NDiS V1100 supports four display outputs and flexible peripheral integration for scanners, readers, and a wide range of other peripherals. The fanless NDiS V1100 player can withstand room temperature and extended temperature conditions. Its outdoor applications include QSR drive-through kiosks, box office displays, information booths, bus stops, and digital transit information signs. It is also excellent for digital signage, supplying improved performance and fresh immersive experiences for branding, hospitality, and advertising.

Key Features:

  • 11th Gen Intel Core (Tiger Lake UP3) processor SoC
  • Dual non-ECC DDR4 3200 SO-DIMM, support up to 32Gb
  • Onboard M.2 2280 Key M with PCIe x4 signal for storage modules
  • Onboard mini-PCIe for optional Wi-Fi or LTE module
  • 4 x HDMI 2.0, support [email protected]
  • Dual LAN ports and 3 x USB 3.0 ports
  • Fanless design
CPU Support

Onboard 11th Gen Intel Core i3-1115G4E processor, dual-core, 2.2 GHz, 6M cache

Onboard 11th Gen Intel Core i5-1145G7E processor, quad-core, 1.5 GHz, 8M cache

Onboard 11th Gen Intel Core i7-1185G7E processor, quad-core, 1.8 GHz, 12M cache (by request)

Chipset SoC (codenamed Tiger Lake UP3)
Main Memory 2 x 260-pin DDR4 SO-DIMM, supports non-ECC, un-buffered memory up to 64G
Graphics & Display

Intel UHD graphics on i3 processor

Intel Iris Xe graphics on i5 and i7 processor

4 x HDMI, support 4096 x [email protected]


1 x power button with LED


2 x DB9
- COM1: RS232/422/485
- COM2: RS232

I/O Interface-Rear

1 x 4-pin DC Jack, 12V

4 x HDMI

2 x RJ45 Intel Gigabit LAN port
- 1 x Intel I219-LM GbE PHY
- 1 x Intel I225-V GbE LAN
3 x USB 3.01 x USB 2.0

I/O Interface-Internal

4 x USB 2.0, internal connector

1 x Mic-in/Line out, internal connector

1 x Speaker out with 2W/4Ω amplifier, internal connector

8 x GPIO pin header for 4 x GPI and 4 x GPO

1 x 4-pin connector for PWM smart fan

Onboard TPM2.0

Storage 1 x M.2 2280 Key M (PCIe Gen4 x4, SATA III), support optional storage modules
1 x SATA & SATA power connector
Expansion 1 x M.2 3052 Key B, support optional 5G modules
1 x mini-PCIe, support optional 4G/Wi-fi/Bluetooth modules
Power Supply

1 x External 96W AC/DC power adapter

Input: 100V AC to 240V AC

Output: DC+12VDC


Operating temperature: V1100 (0°C to 45°C)

Storage temperature: -20°C to 80°C

Humidity: 10 to 90% (non-condensing)


CE Approval

FCC Class A

Dimensions 190mm (W) x 165mm (D) x 51.1mm (H) (without wall mount bracket)
Operating System Support Win10/Linux
We build to order
