nROK7280-5WIC5IP Fanless IP67 AI Railway Computer with Intel Core Ultra
Fanless, IP67 AI-Powered Railway Computer Powered by Intel Core Ultra Processor (Series 1)
Key Features:
- Powered by Intel® Core™ Ultra processor, up to 26 TOPS AI computing power
- Fanless, IP67-rated and rugged design
- 5 x 2.5GbE PoE, M12 X-coded, one port supporting PoE++ (IEEE 802.3bt)
- Expandable to 2 x WWAN and 2 x WLAN for enhanced mobile router performance
- Support 100/1000Base-T1 Automotive Ethernet (optional)
- 1 x 2.5” SSD, 1 x M.2 Key B+M SSD and 1 x NVMe SSD (PCIe 4.0 x4) for data integrity
- DC 24V~110V input w/ power isolation, ignition control and OCP/OVP
- Wide range operating temperature of -40°C~60°C/EN 50155 (OT2)
- MIL-STD military standard for anti-vibration/shock
- CE/FCC, UKCA, EN 50155 and EN 45545-2 certified
Description
Product Overview
The NEXCOM nROK 7280-7WIC5IP and nROK 7280-5WIC5IP are rugged fanless railway computers designed for rolling stock, onboard surveillance and intelligent transport applications. Powered by Intel Core processors, these systems deliver high-performance processing for video analytics, infotainment and edge computing while meeting the demands of harsh railway environments. With integrated PoE support, advanced wireless connectivity and EN50155 compliance, the nROK 7280 series is built for reliable deployment across rail and transportation systems.
Key Features
High Performance Railway Computing
-
Intel Core processor platform for advanced edge processing workloads
-
Designed for surveillance, infotainment and AI-enabled transport applications
-
Supports high-performance multimedia and real-time data processing
-
Optimised for continuous operation in rolling stock environments
Integrated PoE Connectivity
-
Multiple IEEE 802.3af/at PoE ports for powering connected devices
-
Suitable for IP cameras, wireless access points and onboard systems
-
Simplifies installation by reducing separate power cabling
-
Supports centralised device integration across rail deployments
Advanced Wireless Communication
-
Supports WiFi 5 and cellular communication modules
-
Optional LTE and 5G connectivity for wide area communication
-
GNSS support for accurate positioning and fleet management
-
Designed for stable communication in mobile environments
Rugged Railway Design
-
EN50155 compliant for railway applications
-
Fanless construction for silent operation and reduced maintenance
-
Resistant to vibration, shock and fluctuating power conditions
-
Wide operating temperature support for harsh transport environments
Flexible Storage and Expansion
-
Supports SSD storage for reliable, high-speed data access
-
Expansion capability for wireless, storage and communication modules
-
Designed for scalable transport and edge deployments
-
Suitable for video recording and data-intensive workloads
Rich Industrial Connectivity
-
Multiple Ethernet ports for network integration
-
USB and serial interfaces for peripherals and industrial devices
-
Digital I O support for system monitoring and control
-
Designed for integration into onboard transport systems
Applications and Use Cases
The nROK 7280 series is suitable for:
-
Railway and rolling stock systems
-
Mobile video surveillance and NVR applications
-
Passenger infotainment systems
-
Wireless gateway and onboard communication
-
Edge AI and intelligent transport deployments
Dimensions/Drawings
Download
More Information
| Brand | Nexcom |
|---|---|
| Specifications |
|
Ordering Information
SKU: nROK 7280-5WIC5IP (P/N: 10A00728003X0)
Intel® Core™ Ultra 5 processor 125H, IP67 rated, 1 x 2.5GbE PoE++, 4 x 2.5GbE PoE+, 1 x USB 3.2, 4 x USB 2.0, 4 x Serial, 1 x 2.5”SSD, 4DI/4DO, 2 x CAN FD, DC 24V~110V power isolation, IGN control
