OPS500-520H, 8th gen LGA1151 i series CPU, Intel H310

SKU: OPS500-520H

Open Pluggable Specification (OPS) Digital Signage Player with LGA1151 Socket 8th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor, Intel® H310 and TPM 2.0

Datasheet

Description

Open Pluggable Specification (OPS) Digital Signage Player with LGA1151 Socket 8th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor, Intel® H310 and TPM 2.0



·         Intel® Open Pluggable Specification (OPS compliance)

·         8th gen Intel® Core™ i7/i5/i3 & Celeron® processors (Coffee Lake-S)

·         2 DDR4-2400 SO-DIMM for up to 32GB of memory

·         1 M.2 Key M for SATA storage

·         1 M.2 Key E for Wi-Fi solution

·         USB 3.1 Gen1 supported

·         Supports Trusted Platform Module (TPM) 2.0

·         Easy installation and maintenance

Download

Data sheet
User Manual

More Information

Brand Axiomtek
Specifications
CPU
  • LGA1151 socket 8th gen Intel® Core™ i7/i5/i3 and Celeron® processor, 35W TDP
Chipset
  • Intel® H310
System Memory
  • 2 x 260-pin SO-DIMM DDR4-2400, up to 32GB
BIOS
  • AMI
COM
  • 1 x RS-232
USB
  • 2 x USB 2.0
  • 2 x USB 3.1 Gen1 Type A
Ethernet
  • 1 x 10/100/1000 Mbps (Intel® i219-LM)
Display
  • 1 x HDMI 1.4b with 4K resolution
Audio
  • N/A
JAE Connector
  • 1 x DisplayPort with 4K 60Hz supported
  • 1 x HDMI 2.0 with 4K 60Hz supported
  • 2 x USB 2.0
  • 1 x USB 3.0
  • 1 x Audio (Line-out)
  • 1 x UART (TX/RX)
HRS Connector
  • N/A
Wi-Fi
  • 802.11 b/g/n (optional)
Storage
  • 1 x M.2 Key M for SATA storage
Expansion
  • 1 x M.2 Key E 2230 for Wi-Fi
Power Supply
  • 1 x 12 VDC power input (adapter available by option)
Watchdog Timer
  • 255 levels, 1 to 255 sec.
Operating Temperature
  • 0°C to +45°C (+32°F to +113°F) (with airflow 1.2m/s)
Dimensions
(W x D x H)
  • 200 x 119 x 30 mm (7.87” x 4.68” x (1.18”)
Weight (net/gross)
  • 1 kg (2.21 lb)/1.5 kg (3.3 lb)
Certifications
  • CE, FCC Class A
