PC25, Pentium J5005, 3x expandable storage
PC25, Pentium J5005, 3x expandable storage
Compact OPS player, Intel® Pentium J5005 or Intel® Celeron J4105
Description
Compact OPS player, Intel® Pentium J5005 or Intel® Celeron J4105
· Intel Gemini Lake Pentium/Celeron Processor
· 2 x SO-DIMM DDR4, up to 8GB
· 1 x JAE (DP/HDMI), 1 x HDMI, Supporting 4K Display
· 1 x 2.5” SATA, 1 x mSATA, 1 x M.2
· 2 x USB3.0, 2 x USB2.0, 1 xRS232
· 1 x RJ45, 1 x M.2 (2230) for WiFi/BT
More Information
|
Brand |
Giada Technology Inc. |
|
Specifications |
| PC25 |
PC25-N1-J500540H0G-GIA / PC25-N1-J410540H0G-GIA |
| Processor |
CPU |
Intel® Pentium J5005 / Intel® Celeron J4105 |
| Frequency |
1.5GHz (up to 2.8GHz) / 1.5 GHz (up to 2.5GHz) |
| BIOS |
AMI Source Code |
| Chipset |
SOC |
| Memory |
Type |
DDR4-2133MHz |
| Socket |
2 x SO-DIMM |
| Max Size |
8GB |
| Graphics |
GPU |
Intel® HD Graphics 605/600 |
| Graphic Engine |
DirectX ,OpenGL |
| DP（80Pin JAE OPS） |
1 x DP 1.2 (Max.4096 x 2160@60Hz) |
| HDMI（80Pin JAE OPS） |
1 x HDMI 2.0 (Max.4096 x 2160@60Hz) |
| HDMI |
1 x HDMI 1.4 (Max.3840 x 2160@30Hz) |
| Network |
Controller |
Realtek RTL8111H Gigabit Ethernet |
| Interface |
1 x RJ45 |
| I/O |
USB |
2 x USB 3.0, 2 x USB 2.0 |
| Serial Port |
1 x RS232 |
| Audio |
1 x 2-in-1 Headset (MIC-IN & AUDIO-OUT) |
| Mini-PCIe |
1 x Full-size Mini-PCIe for mSATA |
| M.2 1# |
1 x M.2 (2230 ) for WiFi/BT |
| M.2 2# |
1 x M.2 (2242/2280) for SSD |
| Storage |
SATA |
1 x 2.5"SATA |
| mSATA |
1 x Full-size Mini-PCIe for mSATA |
| M.2 |
1 x M.2(2242/2280) for SSD |
| JAHC Tech |
WatchDog Timer |
0~255 Second Time Out Support |
| Auto Power On |
Power Activated Automatically Start |
| RTC |
Set Up Independently Every day, A Week as a Cycle |
| Wake On Lan |
Yes |
| Operation System |
Windows |
Windows 10(64-bit) |
| Linux |
Supported |
| Power |
Power Type |
DC-IN |
| Input Voltage |
19V/3.42A |
| Mechanical |
Dimensions (W × D × H) |
200mm x 119mm x 30mm(7.87"x4.96"x1.18") |
| Construction |
Metal |
| Color |
Black |
| Environment |
Operating Temperature |
0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow |
| Relative Humidity |
95%@40℃ (non-condensing) |
| Certification |
Certification |
CE, FCC Class B, CCC |
|
