PC67 i7 Compact OPS Player

In stock
Brand: Giada Technology Inc.


This product is now end of life. There may still be stock available; get in touch with us for more details or suggestions for appropriate replacements.

Enquire Now
Enquire about this product:

Compact OPS player, Intel Celeron 3865U, Intel i3-7100U, Intel i5-7200U, Intel i7-7500U


·         Intel 7th Generation Core Processor

·         2 x SO-DIMM DDR4, up to 32GB

·         1 x JAE (DP/HDMI), 1 x HDMI, Supporting 4K Display

·         1 x 2.5” SATA, 1 x mSATA, 1 x M.2

·         2 x USB3.0, 2 x USB2.0, 1 xRS232

·         1 x RJ45, 1 x M.2 (2230) for WiFi/BT

·         Supports Intel vPro Technology (optional)

This product is listed in Digital Signage

 PC67-N1-3865U40H0G-GIA / PC67-N1-7100U40H0G-GIA /

PC67-N1-7200U40H0G-GIA / PC67-N1-7300U40H0G-GIA/


Processor CPU Intel® Celeron 3865U / Intel® Core i3-7100U /  Intel® Core i5-7200U / Intel® Core i5-7300U/ Intel® Core i7-7500U

1.80GHz / 2.40GHz / 2.50GHz (Up to 3.10GHz ) /

2.60GHz (Up to 3.50GHz ) / 2.70GHz (Up to 3.50GHz )

BIOS AMI Source Code
Chipset SOC
Memory Type DDR4-2133MHz
Socket 2 x SO-DIMM
Max Size 32GB
Graphics GPU Intel® HD Graphics 610/620
Graphic Engine Direct3D 2015, OpenGL 4.5, OpenCL 2.1
DP(80Pin JAE OPS) 1 x DP (Max.4096 x 2304@60Hz)
HDMI(80Pin JAE OPS) 1 x HDMI (Max.3840 x 2160@30Hz)
HDMI 1 x HDMI (Max.3840 x 2160@30Hz)(No sound))
Network Controller

Realtek RTL8111H Gigabit Ethernet

/ Intel I219LM(Optional)

Interface 1 x RJ45
I/O USB 2 x USB 3.0, 2 x USB 2.0
Serial Port 1 x RS232
Audio 1 x 2-in-1 Headset (MIC-IN & AUDIO-OUT)
Mini-PCIe 1 x Full-size Mini-PCIe for mSATA
M.2 1# 1 x M.2 (2230 ) for WiFi/BT
M.2 2# 1 x M.2 (2242/2280) for SSD
Storage SATA 1 x 2.5"SATA
mSATA 1 x Full-size for mSATA
M.2  1 x M.2 (2242/2280) for SSD
JAHC Tech WatchDog Timer 0~255 Second Time Out Support
Auto Power On Power Activated Automatically Start
RTC Set Up Independently Every day, A Week as a Cycle
Operation System Windows Windows 10(64-bit)
Linux Supported
Power Power Type DC-IN
Input Voltage 19V/3.42A
Mechanical Dimensions (W × D × H) 200mm x 119mm x 30mm(7.87"x4.96"x1.18")
Construction Metal
Color Black
Environment Operating Temperature 0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow
Relative Humidity 95%@40℃ (non-condensing)
Certification Certification  CE, FCC Class B, CCC
