PICO317 Pico-ITX SBC Atom x5-E3940

In stock
Brand: Axiomtek

Pico-ITX SBC with Intel® Atom® x5-E3940 Processor, HDMI, LVDS, GbE LAN and Audio

Enquire Now
Enquire about this product:

PICO317 is powered by the onboard quad-core Intel® Atom® x5-E3940 processor. This tiny 2.5-inch embedded board can withstand a wide operating temperature range of -40°C to +70°C (-40°F to +158°F) for use in harsh and space-constraint environments. Supporting dual-display capability through 4K-ready HDMI and 18/24-bit single/dual channel LVDS. This low-power industrial motherboard has a full-size PCI Express Mini Card slot supporting mSATA for wireless and storage. It has three USB 3.0 ports to connect with industrial cameras for machine vision applications. The fanless and ultra-compact design allows easy installation in environments. Combined with a rugged design and high-speed processing, the PICO317 is suitable for a variety of industrial IoT applications, including industrial automation, transportation, retail and more.

  • Dual-core Intel® Atom® x5-E3940 processor (code name: Apollo Lake)
  • 1 DDR3L-1867 SO-DIMM for up to 8GB of memory
  • 2 COM, 2 USB 2.0, and 3 USB 3.0
  • 1 Full-size PCI Express Mini Card slot with mSATA supported
  • Wide operating temperature range from -40°C to +70°C

This product is listed in Digital Signage, Industrial Automation, Gaming, Mining, Medical, Transport, Axiomtek, Embedded Boards
  • Intel® Atom® x5-E3940 processor onboard
  • SoC integrated
System Memory
  • 1 x 204-pin DDR3L-1867 SO-DIMM, up to 8GB
  • AMI
  • 2 x RS-232
  • 2 x USB 2.0
  • 3 x USB 3.0
  • 1 x 10/100/1000 Mbps (Intel® i211-AT)
  • 1 x HDMI
  • 1 x LVDS
Digital I/O
  • N/A
  • HD Codec audio as Line-out with Realtek ALC662
  • 1 x SATA-600
  • 1 x Full-size PCI Express Mini Card slot with mSATA supported
  • Yes; compatible with I2C
  • Lithium 3V/220 mAh
Power Input
  • 2 x 2-pin connector
  • +5V DC-in only
  • AT Auto Power On function supported
Power Requirements
  • Intel® Atom® x5-E3940 @1.6 GHz 8GB DDR3L, min. RMS: +5V @2.9A
Watchdog Timer
  • 65536 levels, 0 to 65535 sec.
Hardware Monitoring
  • Yes
Operating Temperature
  • -40°C to +70°C (-40°F to +158°F)
Relative Humidity
  • 10% to 95% relative humidity, non-condensing
  • 100 x 72 mm
Board Thickness
  • 1.6 mm
  • CE
