Shop PICO318 Pico-ITX SBC

SKU: PICO318PGGA

Pico-ITX SBC with Intel® Pentium® Processor N4200/Celeron® Processor N3350 and J3455, DisplayPort, LVDS, 2 GbE LAN and Audio

Datasheet

Description

Intel® Pentium® processor N4200/Celeron® processor N3350 and J3455

1 DDR3L SO-DIMM for up to 8GB of memory

2 GbE LAN

1 PCI Express Mini Card slot with mSATA supported

M.2 Key B

Data sheet

Brand

Axiomtek

Specifications

CPU	Intel® Pentium® processor N4200 & Celeron® processor N3350 and J3455 onboard
Chipset	SoC integrated
System Memory	1 x 204-pin DDR3L-1867 SO-DIMM, up to 8GB
BIOS	AMI
COM	1 x RS-232/422/485 1 x RS-232
USB	2 x USB 2.0 2 x USB 3.0
Ethernet	2 x 10/100/1000 Mbps (Intel® i211-AT)
Display	1 x LVDS 1 x DisplayPort
Digital I/O	4-channel in/out programmable
Audio	Mic-in/Line-in/Line-out
Storage	1 x M.2 KEY B (SATA, USB 2.0, PCIe x2 optional) in 22 x 42 or 30 x 42
Expansion	1 x Half-size PCI Express Mini Card slot with mSATA supported
Others	1 x I2C
Battery	Lithium 3V/220mAH
Power Input	2 x 2-pin connector +12V DC-in only AT Auto Power On function supported
Power Requirements	Intel® Pentium® N4200 @ 1.1 GHz 8GB DDR3L Max RMS: +12V @1.3A Intel® Celeron® N3350 @ 1.1 GHz 8GB DDR3L Max RMS: +12V @1.1A Intel® Celeron® J3455 @1.5 GHz 8GB DDR3L Max RMS: +12V @1.8A
Watchdog Timer	65536 levels, 1 to 65535 sec.
Hardware Monitoring	Yes
Operating Temperature	-20°C to +60°C (-4°F to +140°F)
Relative Humidity	10% to 95% relative humidity, non-condensing
Dimensions	100 x 72 mm
Board Thickness	1.6 mm
Certifications	CE
