SCM120 SMARC v1.0 SoM with iMX6 Quad/DualLite 800 MHz

In stock
SKU:
SCM120
Brand: Axiomtek

Category: Single Board Computers

SMARC v1.0 SoM with iMX6 Quad/DualLite 800 MHz (Industrial) SoC, 1GB RAM, 4GB eMMC, GbE LAN, Audio, CAN, MIPI and PCAM


Downloads:

pdf
Data sheet
Enquire Now
Enquire about this product
main product photo
We build to order

SMARC 1.0 (82 x 50 mm)

Ultra low power consumption Cortex™-A9

2 CAN 2.0B

24-bit TTL signal

LVDS/HDMI 1080P

10/100/1000 Mbps Ethernet

Linux3.0.35/Android 4.3

Audio


This product is listed in Industrial Automation, Mining, Transport, Axiomtek, Embedded Boards
Specifications
CPU
  • Freescale i.MX6 Series SoC with Quad/DualLite ARM Cortex™-A9 CPU 800 MHz
Chipset
  • SoC integrated
System Memory
  • Onboard DDR3-1600, up to 1GB
OS
  • Linux kernel 3.0.35
  • Android 4.3
COM
  • 3 x COM with TX/RX/RTS/CTS
  • 1 x Console port
USB
  • 1 x USB 2.0
  • 1 x OTG client
Ethernet
  • 1 x 10/100/1000 Mbps
Display
  • 1 x 24-bit TTL signal
  • 1 x Dual channel 24-bit LVDS
  • 1 x HDMI 1080P
CAN
  • 2 x CANBus 2.0B
I2C
  • 4 x I2C
SPI
  • 1 x SPI
GPIO
  • 8 x GPIO
Audio
  • 1 x Audio (Mic-in/Headphone)
Storage
  • 1 x eMMC flash 4 GB
  • 1 x SDIO interface
  • 1 x SATA interface (only quad support)
Expansion
  • 1 x PCle
Others
  • 1 x MIPI v1.0, 2 x Lane
  • 1 x PCAM 8-bit
Battery
  • Battery on the Baseboard is required
Power Requirement
  • +3V to +5.25V
Operating Temperature
  • -40°C to +85°C (-40°F ~ +185°F)
Relative Humidity
  • 10% to 95%, non-condensing
Dimensions
  • 82 x 50 mm
Board Thickness
  • 1.2 mm ± 0.1 mm
Certifications
  • CE
