Enclosure: plastic PC + ABS Mounting: support VESA mount: 75mm x 75mm Power input: 24VDC Power consumption: 14W Ingress protection: front panel IP54 Dimension: 207mm (W) x 173mm (H) x 36.7mm (D) (8.15" x 6.81" x 1.44") Weight (net): around 0.8Kg, 1.76Lb
LCD Panel
8-inch TFT LCD panel with LED backlight 800 x 600 pixels (SVGA) Brightness: 1,000 cd/m² (typical) Contrast ratio: 500: 1 (typical)
Touch Screen Sensor
4-wire resistant touch Anti-glare coating surface
I/O Interface-Front
On screen display buttons x 5 - Power on/off - Brightness control (+/-) - Volume control (+/-) Light sensor 2 x LED indicators 2 x Built-in speakers (1.2W)
I/O Interface-Lateral
1 x USB type A for storage 1 x Line-out (automatic detection/switch to external speaker) 1 x Mic-in
I/O Interface-Bottom
1 x Remote button to power on/off the system 1 x DB9 (male, integrating USB, power, video, audio and DO) to connect with the system 1 x DB9 (female) for analog camera x 4 (CVBS)
